How to disassemble the wire cutting motor? [Zhikai CNC professional answer]

Wire cutting motor is a common industrial equipment used to cut metal materials. After using it for a period of time, it may be necessary to disassemble and repair the wire cutting motor. Here are the steps to disassemble the wire cutting motor:

1. Preparation:

First, make sure the wire cutting motor is powered off and unplug the power plug. Then, prepare the necessary tools, such as wrenches, screwdrivers, pliers, etc.

2. Remove the outer shell:

Use a screwdriver or wrench to remove the wire cut motor housing. Usually, there are several screws on the housing, loosen them and remove the housing.

3. Disconnect the power cord:

Locate the connection point for the power cord, usually on the bottom of the motor. Using a wrench or pliers, loosen the cord's connection nut and pull the cord away from the motor.

4. Disassemble the cutting head:

The cutting head is the core component of the wire cutting motor and needs to be disassembled carefully. First, find the fixing screw of the cutting head and loosen it with a screwdriver or wrench. Then, carefully remove the cutting head from the motor.

5. Disassemble the motor:

Remove the motor from the base, which usually requires loosening a few screws. Using a wrench or screwdriver, loosen the screws and remove the motor.

6. Inspection and maintenance:

Once the motor is disassembled, it can be inspected and repaired. Check the motor for damaged or worn parts, such as bearings, insulation, etc. If there are parts that need to be replaced, new parts can be purchased and replaced.

7. Assembly:

After you have completed the repair, reinstall the motor onto the base. Make sure the screws are tight and secure. Then, install the cutting head back onto the motor and tighten the retaining screws. Finally, connect the power cord back to the motor and tighten the connecting nut.

8. Install the housing:

Install the housing of the wire cutting motor back to its original position and tighten the screws. Make sure the housing is firmly installed.
The above are the steps to disassemble the wire cutting motor. When disassembling and repairing, be sure to operate carefully to avoid damaging the motor or getting injured. If you are not familiar with disassembling and repairing wire cutting motors, it is recommended to ask professionals to do it.
